| Battery System Side | |
|---|---|
| Model | HV-768V 280AH*3P |
| Rated voltage | 768V |
| Rated capacity | 840ah(0.2C) |
| Charge voltage | 852VDC(adjustable) |
| Discharge voltage | 672VDC |
| Rated working current | 300A(0.35C) |
| Protection level | IP65 |
| Communication | two way CAN2.0/RS485 |
| PCS Technical Specifications | |
|---|---|
| PCS DC Input Voltage | 420-850VDC |
| Max Photovoltaic Power | 360KW |
| Rated AC Power | 275KVA |
| MPPT Range | 250-850VDC |
| Communication | RS485/CAN |
| Grid Certification | TUV, CE |
SunArk Power is a leading global energy storage solution and service provider. The company specializes in residential, commercial and utility applications and delivers pre-eminent products and fit-for-purpose solutions. SunArk Power has 20+ experience producing energy storage products and 90,000+ systems actively running in 80+ countries, enabling millions of people to enjoy reliable, accessible and clean energy. SunArk Power has been developing quickly, till end of 2022, accumulatively, the company has manufactured 620MWh BESS and battery strings.
